Paint Protection Film Specification
Product function
Paint protective film has excellent uv blocking function, strong impact resistance.can effectively improve the paint anti-uv aging ability, not to change color, yellow.After tearing off the paint, the protective film does not hurt the original car paint, no residual glue, to ensure the car paint as bright as new.Film light permeability, strong waterproof, high temperature resistance, scratch resistance, corrosion resistance, green environmental protection.
This film is a polycaprolactone based, aliphatic TPU (thermal polyurethane) film. It is a low gel, no yellowing, UV-resistant film used in a wide range of outdoor exposed vehicle protection applications.
CXOC PPf Model one
TOP COATING SURFACE PROPERTIES
Nano glass ceramic top coat
Extreme water repellent performance
Extreme high-gloss and optical clarity
Self-healing from minor scratching, etc.
Anti-contamination, no-yellowing
FILM CONSTRUCTION
-Cap sheet
Removable protective polyester film
-Clear coat
Flexible, self-healing polyurethane coating
-Urethane
Impact-resistant 5mil urethane formulated for excellent
UV, heat and water resistance
-Adhesive
Self-crosslinking acrylic copolymer adhesive formulated
for balanced tack, adhesive and cohesive properties
-Liner
Matte, polyester release liner
CXOC PPF MODEL ONE SPECIFICATIONS
Features & benefits
Virtually invisible shield that helps protect vehicle’s appearance
Helps defend against abrasions, nicks and scratches from insects, small road debris and winter salt and sand (year-round protection)
Applicable to bonnets, mirrors, bumpers, fenders, door handles, door edges, boot sills and more
A proprietary, self-healing clear coat that is scratch- and crack-resistant
High-gloss, virtually invisible surface with superior optical clarity that matches a new car’s finish
Helps to maintain investment and to maximise future trade-in value
Professional installation by qualified dealers ensures quality
·Thickness - 203 mic
·Urethane: Lubrizol USA
·Topcoat (top coat) - soft (nanoclear USA)
·Adhesive layer (glue) - Ashland (USA)
Maximum stretch (stretch max) - 430%
Hydrophobic properties 107°
Maximum temperature 120°
Tensile strength 5000psi
Peel off at 850 n\m
The average service life is 6-8 years.
Product Thickness(Total) 8 mil±0.3mil
Thickness (Clear Coat) 0.26 mil
Thickness (Base Film) 6.0mil
Thickness (Adhesive) 1.2mil
Thickness (Liner) 3.5mil
Peel Adhesion (850N/m)
Tensile Strength 5000 psi
Elongation at Break >430%
Chemical Resistance No Detrimental Effect
Weathering No Detrimental Effect
Acid Immersion No Detrimental Effect
Base Immersion No Detrimental Effect
Rock Chip Resistance Pass
CXOC PPF MODEL 2 SPECIFICATIONS
Features & benefits
Virtually invisible shield that helps protect vehicle’s appearance
Helps defend against abrasions, nicks and scratches from insects, small road debris and winter salt and sand (year-round protection)
Applicable to bonnets, mirrors, bumpers, fenders, door handles, door edges, boot sills and more
A proprietary, self-healing clear coat that is scratch- and crack-resistant
High-gloss, virtually invisible surface with superior optical clarity that matches a new car’s finish
Helps to maintain investment and to maximise future trade-in value
Professional installation by qualified dealers ensures quality
·Thickness - 190 mic
·Urethane: Lubrizol USA
·Topcoat (top coat) - soft (nanoclear USA)
·Adhesive layer (glue) - Ashland (USA)
Maximum stretch (stretch max) -400%
Hydrophobic properties 107°
Maximum temperature 110°
Tensile strength 5000psi
Peel off at 800 n\m
The average service life is 6-8 years.
Product Thickness(Total) 7.5 mil±0.3mil
Thickness (Clear Coat) 0.26 mil
Thickness (Base Film) 5.5mil
Thickness (Adhesive) 1.2mil
Thickness (Liner) 3.5mil
Peel Adhesion (800N/m)
Tensile Strength 5000 psi
Elongation at Break >400%
Chemical Resistance No Detrimental Effect
Weathering No Detrimental Effect
Acid Immersion No Detrimental Effect
Base Immersion No Detrimental Effect
Rock Chip Resistance Pass
